Waste Incinerator
(Containerized Mobile Incinerator)
Capacity: Average 50 kgs per hour
Model |
CA50 |
Internal Dimensions |
100 x 80 x |
Main Product List |
Primary Combustion Chamber |
Secondary Combustion Chamber |
|
Smoke Filter Chamber |
|
Incinerator Control Case |
|
Chimney:5.0Meters *(upgrade to Stainless Steel, free cost) |
|
|
|
Oil Tank (if oil fuel): 200Liters |
|
ISO 20′ Container(Delivery with Incinerator) |
Model |
CA50 |
Waste Treatment |
Waste Incineration Treatment |
Feed Capacity |
Average 100 kgs per feed |
Burning Rate |
Average 50 kgs per hour |
Burning Time per Feed |
Average 2 hour |
Control Mode |
PLC(Programmable Logic Controller Incinerator) |
Voltage |
220V |
Power |
0.7Kw |
Fuel |
Diesel oil |
Burner |
|
Feed Mode |
Manual |
Temperature Monitor |
Digital Display |
Fuel consumption (Oil) |
Average 16.6 Kgs/Hour |
Internal Dimensions |
100x80x |
External Dimensions |
230 x 130 x |
Waste combustion chamber |
560Liters |
Post Combustion Chamber |
280Liters |
Oil Tank Capacity |
200 Liters |
Door Opening |
70 x |
Chimney |
|
Gross Weight |
4500kgs |
Chamber Material |
Firebrick ,Refractory Concrete |
Max. Heat Value |
166,000Kcal/Hr. |
